Laser range finder Power supply DC/DC fly back
Technical parameters:
Input voltage 10-24 V DC
Output voltage 5 V DC / 1A
Output voltage 12 V DC / 0.5 A
Output voltage 140 V DC / 0.02A
Output voltage 1200 V DC / 0.002A
Output voltage 300 V DC / 0.2A
Output power 12 W

SM power supply

Power supply AC/DC push-pull

Technical parameters:
Input voltage 170 - 250 VAC
Output voltage 7 V DC / 2A
Output power 14 W

SMPS

Power supply AC/DC step-down
Technical parameters:
Input voltage 20 - 100 VAC
Output voltage 17 V DC / 15 A
Output power 255 W

SMPS1
Power supply DC/DC fly back (project DP-EP)
Technical parameters:
Input voltage 24-34 VDC
Output voltage 5VDC/ 0.5A
Output voltage 110VDC/ 2mA
Output voltage -110VDC/ 2mA
Output voltage 12VDC/ 50mA
Output voltage -12VDC/ 50mA
Output power 2 W

SMPS2
Power supply DC/DC - COMPASS project
Technical parameters:
Input voltage 20 - 40 VDC
Output voltage 100V DC / 0.002 A
Output voltage ±12 V DC / 0.11 A
Output voltage ±5 V DC / 1 A
Output power 13 W

SMPS3
